| ENGINE |
| Model |
FM 2.6 CR CD |
| Type |
4 Cyl, Common Rail DI |
| Displacement |
2596 cc |
| Emission |
BS-VI stage 2 |
| Max. Engine Output |
67 kW (90 hp) @ 3200 rpm |
| Max. Torque |
250 Nm @ 1400-2400 rpm |
| GEAR BOX |
| Type |
Manual, Gear Lock Synchromesh on forward gears |
| No. of Gears |
5 Forward,1 Reverse |
| STEERING |
| Type / Description |
Power steering Rack & Pinion |
| BODY |
| Type |
Rectangular C-in-C type chassis section |
| SUSPENSION |
| Type / Description |
Front - Independent type, Double wishbone |
| Rear |
Leaf spring |
| SPRINGS |
| Front |
Torsion bar |
| Rear |
Parabolic leaf spring |
| ANTI ROLL BAR |
Yes |
| Shock Absorber |
Hydraulic telescopic double acting both at front & rear |
| BRAKES |
| Service brake |
Dual circuit, Hydraulic, Vacuum assisted with auto wear adjuster |
| ABS, EBD |
Yes |
| Front |
Disc |
| Rear |
Drum |
| Parking brake |
Mechanical acting on rear wheels |
| WHEELS & TYRES |
| Type |
Radial - Tubeless |
| Size |
215/75 R15 LT |
| FUEL TANK |
| Capacity |
63.5 Litres |
| AdBlue |
20 |
| DIMENSIONS (mm) |
| Wheel base |
3050 |
| Overall width |
1818 |
| Overall length |
5120 |
| Overall height |
2027 |
| Min.Ground clearance : |
191 |
| WEIGHT (kg) |
| Maximum GVW |
3180 |
| SEATING CAPACITY |
| Seating Capacity |
9+D |
